Peb theem -roj -immersed faib transformersiv hom tshiab insulating qauv. Cov tub ntxhais hlau yog ua los ntawm high-zoo txias-silicon dov- cov hlau phaj. High-voltage winding pab pawg yog tsim los ntawm siab- zoo oxygen- cov kab tooj liab dawb thiab nws siv ntau- txheej nruas hom qauv. Tag nrho cov fasteners tau ua tiav nrog kev kho tshwj xeeb los tiv thaiv lawv los ntawm kev xoob.
Raws li qib siab - cov khoom siv thev naus laus zis uas txhawb nqa los ntawm lub tebchaws, cov khoom lag luam muaj ntau yam zoo xws li kev ua haujlwm siab, kev poob qis. Nws cov txiaj ntsig kev sib raug zoo yog qhov zoo tshaj plaws uas nws yuav txuag tau ntau ntawm kev siv hluav taws xob thiab cov nqi khiav lag luam.
roj immersed hwj chim transformers
Roj Immersed TransformerPerformance Parameters
| Rated peev (KVA) | Voltage Combination thiab kais ntau yam | kev sib txuas ntawm transformer winding | Tsis muaj -load poob (W) | Load poob (W) | Tsis muaj -load tam sim no (%) | luv Circuit Court impedance (%) | ||
| High voltage (KV) |
High voltage kais ntau ( %) |
Tsawg voltage (KV) |
||||||
| 30 50 63 80 100 125 160 200 250 315 400 500 630 800 1000 1250 1600 |
11 10.5 10 6.3 6 |
±5% ±2x2.5% |
0.4 0.69 |
Yyn 0 Dyn 11 |
100 130 150 180 200 240 280 340 400 480 570 680 810 960 1150 1360 1640 |
630/600 910/870 1090/1040 1310/1250 1580/1500 1890/1800 2310/2200 2730/2600 3200/3050 3830/3650 4520/4300 5410/5150 6200 7500 10300 12000 14500 |
2.3 2.0 1.9 1.9 1.8 1.7 1.6 1.5 1.4 1.4 1.3 1.2 1.1 1.0 1.0 0.9 0.8 |
4 4 4 4 4 4 4 4 4 4 4 4 4.5 4.5 4.5 4.5 4.5 |
Roj Immersed Distribution Transformers Advantage Of Structure
- Peb ntiav kauv coil nrog cov roj ntev txoj kev los ua kom muaj kev ua kom txias sab hauv zoo dua;
- Peb txhim kho kev txhawb nqa zoo ntawm lub coil lub davhlau ya nyob twg nto kom ntxiv dag zog rau kev tiv thaiv - luv luv tam sim no muaj peev xwm.
- Peb ntiav cov qauv hoisting tshiab thiab lub cev -txoj haujlwm thav duab los lav tias kev thauj mus los ntev thiab kev txav mus los yuav txhim khu kev qha;
- Tshem tawm cov roj tank, cov nthwv dej tis ntawm lub tank es tsis txhob siv cov tubing ua cov khoom cua txias, corrugated tank yog ua los ntawm cov ntawv txias txias rau ntawm lub tshuab siab thiab txhim khu kev ntseeg tau ntawm kev khiav.
Peb Transformers Khoom Zaub
Cov teb ntawm daim ntawv thov
peb lub Hoobkas gNEE
Ntim & shipping
xeem creatificate
neeg tuaj xyuas rooj plaub
GNEE Teams
GNEE muaj 16 xyoo dhau los ntawm kev ua haujlwm thoob ntiaj teb lub zog thiab tau pab ntau tus neeg siv khoom thoob ntiaj teb ua tiav cov haujlwm fais fab. Piv txwv li, Canada, Mexico, Panama, Ecuador, Guatemala, Honduras, Chile, El Salvador, Australia, New Zealand, Spain, Belgium, Algeria, South Africa, Ethiopia, Myanmar, Kazakhstan, thiab lwm yam. Daelim kuj muaj zoo heev tom qab- pab pawg muag khoom installation txawv teb chaws, yog li yog tias koj muaj kev xav tau transformers, koj tuaj yeem tiv tauj peb.
FAQ
1.Q: Koj puas yog cov chaw tsim khoom?
A: Yog, peb yog cov chaw tsim khoom. Peb lub Hoobkas nyob hauv Henan Tuam Tshoj.
2.Q: Kuv puas tuaj yeem tau txais kev lees paub ntawm cov khoom?
A: Yog, txhua yam khoom yog 1 xyoo lav zoo raws li tus neeg siv khoom siv cov khoom.
3.Q: Koj puas muaj daim ntawv pov thawj?
A: Yog. Txhua chav tsev muaj CCC, ISO9001 daim ntawv pov thawj. Tag nrho cov khoom siv hluav taws xob nrog daim ntawv pov thawj CE, Yog tias koj xav tau lwm daim ntawv pov thawj, peb tuaj yeem pab koj kom tau txais nws.
4.Q: Yuav ua li cas yuav nws? Yuav ua li cas txog kev xa khoom?
A: Thov hu rau kuv ntawm email lossis hauv online, qhia rau kuv paub koj qhov xwm txheej, kuv yuav muab kev daws teeb meem rau koj.Peb muaj tus neeg sawv cev shipping tuaj yeem xaiv tus nqi pheej yig tshaj plaws thiab xa khoom sai tshaj plaws. FOB, CIF, C & F lossis EXW tsis muaj teeb meem rau peb.
5.Q: Kuv tuaj yeem them koj li cas?
A: T / T, L / C yog siv tau zoo heev.
Cim npe nrov: roj-immersed voltage faib fais fab transformer, Tuam Tshoj roj-immersed voltage tis fais fab transformer manufacturers, lwm tus neeg, Hoobkas
