TS EN 10346 Kev qhia tshwj xeeb thiab kev ua tau zoo rau ntau hom kub-dip galvanized (Z), zinc- aluminium alloy (ZA), zinc-magnesium alloy (ZM), zinc- hlau alloy (ZF), thiab aluminium-zinc alloy (AZ) coated steel.
GNEE Steel, raws li tus kws tshaj lij kev lag luam ntawm kub-dip galvanized steel, tau cog lus los muab siab- cov hlau zoo uas ua tau raws li EN 10346 cov qauv, xws li:S250 GD, S280GD, S320GD, S350GD, S390GD, S420GD, thiab lwm yam., feem ntau yog siv rau hauv Cov Khoom Siv Khoom Siv.
Cov yam ntxwv tseem ceeb ntawm EN 10346 Standard Steels
| Cov qauv | ||||||
| Qib | Steel qib no. | IB 17162/2 | ASTM A466 M | TIAB SA 2989 | NF A 36-322 | TIAB SA 5783 |
| S250 GD | 1.0242 | STE 250-2Z | Qib B | Z 25 | C 250 | Fe E250 G |
| S280 GD | 1.0244 | STE 280-2Z | Qib C | Z 28 | C 280 | Fe E280 G |
| S320 GD | 1.0250 | STE 320-2Z | - | - | C 320 | Fe E320 G |
| S350 GD | 1.0529 | STE 350-2Z | Qib D | Z 35 | C 350 | Fe E350 G |
| S390 GD | 1.0238 | - | - | - | - | - |
| S420 GD | 1.0239 | - | - | - | - | - |
| S450 GD | 1.0233 | - | - | - | - | - |
| Feasibility ntau | |||
| Qib | Thickness | Dav | |
| min. | max. | max. | |
| S250 GD | 0.3 | 4.0 | 1520 |
| S280 GD | 0.3 | 4.0 | 1520 |
| S320 GD | 0.3 | 4.0 | 1520 |
| S350 GD | 0.38 | 4.0 | 1520 |
| S390 GD | 0.49 | 3.5 | 1520 |
| S420 GD | 1.38 | 3.5 | 1520 |
| S450 GD | 0.90 | 3.0 | 1520 |
Kev ua tau zoo ntawm kev sib xyaw tshwj xeeb ntawm thickness thiab dav yuav tsum tau txheeb xyuas nyob rau theem kev txiav txim.
| Mechanical zog | |||||
| Qib | Yield zog | Tensile zog | Elongation | ||
| MPa | MPa | % | |||
| S250 GD | Ntau dua lossis sib npaug li 250 | Ntau dua lossis sib npaug rau 330 | Ntau dua lossis sib npaug li 19 | ||
| S280 GD | Ntau dua lossis sib npaug li 280 | Ntau dua lossis sib npaug rau 360 | Ntau dua lossis sib npaug li 18 | ||
| S320 GD | Ntau dua lossis sib npaug rau 320 | Ntau dua lossis sib npaug rau 390 | Ntau dua lossis sib npaug li 17 | ||
| S350 GD | Ntau dua lossis sib npaug li 350 | Ntau dua lossis sib npaug rau 420 | Ntau dua lossis sib npaug li 16 | ||
| S390 GD | Ntau dua lossis sib npaug rau 390 | Ntau dua lossis sib npaug rau 460 | Ntau dua lossis sib npaug li 16 | ||
| S420 GD | Ntau dua lossis sib npaug rau 420 | Ntau dua lossis sib npaug rau 480 | Ntau dua lossis sib npaug li 15 | ||
| S450 GD | Ntau dua lossis sib npaug li 450 | Ntau dua lossis sib npaug rau 510 | Ntau dua lossis sib npaug li 14 | ||
| Nto tiav | |||
| qib | NA | MA | MB |
| mm | mm | mm | |
| S250 GD | 0.3 - 4.0 | 0.3 - 4.0 | 0.3 - 3.2 |
| S280 GD | 0.3 - 4.0 | 0.3 - 4.0 | 0.3 – 3.2 |
| S320 GD | 0.3 - 4.0 | 0.3 - 4.0 | 0.3 – 3.2 |
| S350 GD | 0.38 - 4.0 | 0.38 - 4.0 | 0.38 – 3.2 |
| S390 GD | 0.49 – 3.5 | 0.49 – 3.5 | 0.49 – 3.2 |
| S420 GD | 1.38 – 3.5 | 1.38 – 3.5 | 1.38 – 3.2 |
| S450 GD | 0.90 – 3.0 | 0.90 – 3.0 | 0.90 – 3.0 |
Txheej
| TS EN 10346 Kev tsim kho | Txheej hnyav - ob sab (g / m²) | Txheej thickness (µm ib sab) |
|---|---|---|
| Z100 | 100 | 7.0 |
| Z140 | 140 | 10.0 |
| Z200 | 200 | 14.0 |
| Z225 | 225 | 16.0 |
| Z275 | 275 | 20.0 |
| Z350 | 350 | 25.0 |
| Z450 | 450 | 31.0 |
| Z600 | 600 | 42.0 |
| Tsis suav nrog tus qauv | ||
| Z80 | 80 | 5.5 |
| Z725 | 725 | 51.0 |
| Rau lwm cov txheej txheem hnyav, thov hu rau peb. | ||
TS EN 10346 Cov Hlau Hlau
Ntim thiab thauj khoom ntawm EN 10346 steel
FAQ
Q1: Koj puas yog ib lub tuam txhab lag luam lossis cov chaw tsim khoom ntawm galvanized steel qauv?
Peb yog cov chaw tsim khoom nrog 3 lub Hoobkas, nrog rau 16 xyoo ntawm kev tsim khoom, tshwj xeeb hauv galvanized coils, galvanized los xij thiab galvanized steel strips.
Q2: Cov ntaub ntawv khoom dab tsi uas kuv yuav tsum tau muab ua ntej kev yuav khoom?
Thov muab qib, dav, thickness, thiab kev kho qhov chaw, nrog rau qhov ntau koj xav tau.
Q3: Koj cov nqe lus them nqi yog dab tsi?
30% T / T ua ntej thiab 70% tshuav nyiaj li cas ua ntej ua zaub mov xa tuaj lossis raws li BL daim ntawv lossis LC thaum pom.
Q4: Nws puas tuaj yeem xa cov qauv?
Tau kawg, peb muab cov qauv dawb thiab nthuav qhia shipping rau cov neeg siv khoom thoob plaws ntiaj teb.
Q5: Koj puas muab kev pabcuam rau cov khoom lag luam customized?
Yog, peb tuaj yeem tsim raws li koj cov specifications thiab kos duab.
Q6: Koj puas tuaj yeem pab kuv hauv kev xa khoom steel thawj zaug?
Yog, peb muaj tus neeg sawv cev shipping uas yuav npaj cov khoom xa tuaj nrog koj.
q7 ua. Koj lub sijhawm xa khoom yog dab tsi?
Hauv 7 hnub ua haujlwm tom qab tau txais koj cov nyiaj tshuav nyiaj li cas.
