Khoom Description
Aluminium Galvanized Steel Coil yog hais txog 55% Al-Zn coated steel khoom, uas tseem hu ua aluzinc steel. GL steel yog zoo haum rau vov tsev thiab siding daim ntaub ntawv, raws li zoo raws li automotive, khoom siv hauv tsev, rooj tog, thiab lwm yam. Vim nws versatility, durability, zoo nkauj tsos, galvalume steel yog nyiam broadly. Yog tias koj tab tom nrhiav rau galvalume steel Hoobkas (GL), thov hu rau GNEE Steel tam sim no.
GNEE Steel muaj ob qho Alu-zinc Steel Chev muag, uas muaj los ntawm AZ30 txog 150. Lub thickness yog los ntawm 0.12 mus rau 2.0 hli thiab qhov dav yog los ntawm 30 mus rau 1500 hli. Tsis tas li ntawd, peb kuj muab kev txiav, slitting, thiab kev pabcuam profile. Txais tos tiv tauj peb rau cov qauv los yog tuaj xyuas peb lub Hoobkas ntawm qhov chaw.
|
Cov qauv |
ASTM / AISI / BS / DIN / JIS / GB thiab lwm yam. |
|
Base hlau |
DX51D/DX52D/DX53D/CGCC/SGCC/SGCH thiab lwm yam. |
|
Thickness |
0 12-2 00mm |
|
Dav |
30-1500 hli |
|
Aluzinc txheej |
30-150g/m² |
|
Txheej txheej |
55% Aluminium+43.5% Zinc+1.5% Silicon |
|
Kev kho saum npoo |
Anti-ntiv tes / Chromated / Skin-pass / Oiled / Qhuav thiab lwm yam. |
|
Hardness |
HRB55-HRB90 |
|
Coil ID |
508-610 hli |
|
Coil Nyhav |
2-10 Tons raws li qhov yuav tsum tau ua |
|
Hom |
Coil / ntawv / sawb / corrugated |
|
Daim ntawv thov |
vov tsev, phab ntsa vaj huam sib luag, cov khoom siv, ntim, cov ntaub ntawv tsim kho thiab lwm yam. |
|
Daim ntawv pov thawj |
ISO9001/ISO14001/SGS/BV/PVOC/SONCAP |
Galvalume Steel Sheet / coil Daim ntawv thov:
|
APPLICATION OF PEB GALVALUME STEEL |
||
|
Kev tsim kho |
Sab nraum |
Rhiav, ua liaj ua teb warehouse, precast chav tsev nyob |
|
corrugated ru tsev, cov menyuam kaw qhov rooj, cov kav dej los nag, cov khw muag khoom lub rooj muag khoom |
||
|
Sab hauv |
Qhov rooj, qhov rooj, lub teeb steel ru tsev qauv, folding screen, of elevator, stairway, ven gutter, Phab ntsa |
|
|
Cov khoom siv hluav taws xob |
Lub tub yees, lub tshuab ntxhua khaub ncaws, hloov cabnet, cuab yeej txee, cua txias, micro-wave owen, khob cij |
|
|
Fuiniture |
Central cua sov hlais, teeb, chifforobe, rooj, txaj, locker, phau ntawv |
|
|
Nqa kev lag luam |
Sab nrauv kho kom zoo nkauj ntawm nws pib thiab tsheb ciav hlau, clapboard, thawv, cais lairage, cais pawg thawj coj saib |
|
|
Qthers |
Sau vaj huam sib luag, khib nyiab, billboard, timekeeper, ntaus ntawv, ntsuas vaj huam sib luag, hnyav sensor, khoom siv yees duab |
|
Nto:
AZ50 vs AZ150 Galvalume hlau:
Muaj ntau yam thicknesses ntawm gl steel ntawv nyob rau hauv coils. Lub galvalume txheej thickness yog qhia los ntawm AZ + tooj. Raws li ASTM A792 Standard, AZ50 galvalume txhais tau tias 0.50 ounces ntawm txhuas zinc txheej ib square feet (ob tog); AZ150 qhia txog Al-Zn txheej hnyav ntawm 1.5 ounces ib square feet ob sab.GNEE Steel muaj AZ30 rau AZ150 galvalume tiav.
Feem ntau, tus lej ntau dua, qhov tuab ntawm Al-Zn txheej. Txheej thickness zoo heev cuam tshuam cov nyhuv tiv thaiv rau lub substrate. Ntawd yog, qhov tuab txheej txheej, qhov zoo dua qhov kav ntev. Yog li ntawd, AZ150 yuav ruaj khov thiab kim dua AZ50.
Vim muaj qhov sib txawv ntawm cov zinc thiab aluzinc txheej, AZ50 tsis zoo ib yam li G50. Lub thickness ntawm G50 galvanized steel yog 10.6 μm ib sab. Thaum Al-Zn txheej thickness ntawm AZ50 yog hais txog 20 μm ib sab. Yog vim li cas AZ50 yuav siv sij hawm ntev dua thiab kim dua G50.
GL Khoom ntim thiab kev thauj mus los:
Customer mus ntsib Case:
GNEE STEEL kev sib tw zoo:
Kev ntseeg tau thiab ruaj khov zoo:
Nrog 16 xyoo ntawm kev xa tawm, lub tuam txhab tau nqis peev ntau hauv kev qhia txog cov khoom siv siab tshaj plaws reversible dov zeb hauv lub teb chaws, uas muaj qhov zoo ntawm kev ruaj khov zoo.
Kev ua haujlwm siab:
Cov khoom yog nyiam los ntawm cov neeg siv khoom. Los ntawm txias dov, lub thickness xav tau los ntawm kev lag luam txawv teb chaws tuaj yeem tau txais, thiab cov khoom lag luam muaj qhov flatness siab, kev ua haujlwm siab punching thiab tus nqi qis. Nws muaj cov ntsiab lus siab tawm los, yog li nws muaj ntau yam kev siv. Nws yog tsim nyog rau tsheb, luam ntawv hlau chim, tsev cov ntaub ntawv thiab lwm yam lag luam. Nws tseem yog cov khoom siv zoo tshaj plaws rau kev tsim cov galvanizing thiab organic xim txheej.
Lub sijhawm xa khoom sai:
Peb lub tuam txhab cov kab hluav taws xob kub-dip galvanizing uas twb muaj lawm tuaj yeem ua tiav cov txiaj ntsig txhua xyoo ntawm 320, 000 tons ntawm cov khoom. Cov kab ntau lawm txais cov txheej txheem US Steel sib koom ua ke. Cov galvanized sawb steel tau tom qab txias cov kub aluminium zinc yog smoothed, kos, thiab passivated. Oiled cov khoom muaj ntau resistant rau corrosion thiab muaj ib tug smoother nto.
FAQ:
Q1: Puas muaj kev tshuaj xyuas zoo rau GL Coils cov khoom ua ntej xa khoom?
A1: Tau kawg, tag nrho peb cov khoom raug soj ntsuam nruj ua ntej ntim, thiab cov khoom tsis tsim nyog yuav raug rhuav tshem. Peb lees txais kev tshuaj xyuas thib peb.
Q2: Kuv puas tuaj yeem tau txais ib qho qauv ua ntej xaj?
A2: Yog lawm, tau kawg. Feem ntau peb cov qauv yog dawb thiab peb tuaj yeem tsim raws li koj cov qauv lossis cov duab kos duab.
Q3: Koj puas tuaj yeem muab kev pabcuam OEM / ODM?
A3: Yog. Thov koj xav tiv tauj peb los tham txog ntau yam ntxiv.
Q4: Cov ntaub ntawv khoom dab tsi kuv yuav tsum tau muab?
A4: Koj yuav tsum muab qib, dav, tuab, txheej thiab tonnage koj xav tau.
