Zinc Aluminium Magnesium (ZAM), yog cov ntawv hlau uas tau tsim los ntawm txoj kev kub-dip, nrog txheej txheej uas muaj 6% zinc, 3% magnesium, thiab txhuas. Qhov kev sib xyaw tshwj xeeb no pub rau ZAM zoo heev corrosion kuj, tiv thaiv xeb tsim ntawm qib 10-20 lub sij hawm zoo dua rau cov hlau galvanized. ZAM coated steel coils yog dav siv nyob rau hauv ntau yam engineering industries, tshwj xeeb tshaj yog nyob rau hauv daim ntawv thov yuav tsum tau durability thiab robust corrosion.
Zinc-aluminium-magnesium (zinc aluminium magnesium) txheej yog los ntawm lub luag hauj lwm ntawm txhuas thiab magnesium, yog li ntawd cov kub dip txheej muaj corrosion kuj zoo heev, hnav tsis kam thiab ua, tuaj yeem siv dav hauv ntau yam. Zinc-aluminium-magnesium coated steel phaj tuaj yeem hloov ncaj qha los ntawm zinc-aluminium-magnesium coated steel phaj yam tsis hloov cov txheej txheem uas twb muaj lawm, sib dhos, txheej thiab lwm yam txheej txheem.
Qhov tseem ceeb tshaj plaws, peb cov ntaub ntawv steel muaj peev xwm muaj xws li slitting, txiav kom ntev, blanking, degreasing thiab txhuam, stretcher leveling thiab metallurgical txhawb.
Parameters ntawm zn al mg coated steel
|
Khoom npe: |
Zinc Aluminium Magnesium Hlau Chev |
|
Txheem: |
ASTM, BS, DIN, JIS, GB |
|
Qauv: |
Muab cov qauv dawb |
|
Khoom siv: |
Tsawg carbon steel |
|
Qib: |
DX51D, TX52D, DX53D |
|
Thickness: |
{0}}12-6.0mm |
|
Dav: |
600mm-1250mm lossis raws li koj qhov kev thov |
|
Ntev: |
1000mm, 2000mm, 3000mm los yog raws li koj qhov kev thov |
|
Txheej Txheej: |
Zn{{0}}.5%Al-1.5%Mg, Zn-2.0%Al-2.0% Mg, Zn-6.0%Al-3.0%Mg lossis raws li koj qhov kev thov |
|
Nto: |
Chromated, un-oiled, Zero spangel, tsis tu ncua spangle |
|
Kev ua tau zoo: |
ruaj, tiv thaiv tus ntiv tes |
|
MOQ: |
Tsis muaj MOQ, qauv txiav txim kuj tau txais. |
|
Muaj peev xwm muab khoom: |
5000t / hli |
|
Lub sij hawm xa tuaj: |
Hauv 15 hnub tom qab tau txais cov nyiaj them ua ntej. |
|
Export Packing: |
Standard Export Seaworthy Pob. |
|
Cov nqe lus them nqi: |
L / C thaum pom, T / T lossis Negotiable. |
|
Daim ntawv thov: |
Tsev Purling / Decking, Tsheb, Khoom Siv Hauv Tsev, PV Mounting / Bracket |
Aluminized Magnesium Zinc Alloy Steel Chev
txheej txheem ntau lawm
Qhov zoo ntawm ZAM txheej
● Lub neej ua haujlwm ntev dua li lwm cov khoom siv coated.
● Txiav ntug xeb tiv thaiv - lub ntsiab feature ntawm ZAM.
● Thinner txheej tsis tau tiv thaiv ntau dua - ecologically tus phooj ywg.
● Zoo heev nyob rau hauv ib puag ncig hnyav - tshwj xeeb tshaj yog ntug hiav txwv dej thiab kev ua liaj ua teb.
● Tshem tawm qhov kev xav tau ntawm kev xa tawm (batch) galvanizing.
● Superior formability vim coating yam ntxwv Tus nqi txuag los ntawm kev pab lub neej ntev dua thiab txo cov txij nkawm.
● Choj cov khoom sib txawv ntawm cov coated galvanized thiab kim stainless hlau.
Ntim ntawm zAM steel phaj thiab kauj
Vim li cas thiaj xaiv GNEE zam coated steel coils?
1. Dav hlau corrosion kuj
GNEE ZAM Steel Coils muaj qhov dav hlau zoo dua corrosion dua li galvanized thiab kub-dip ntshiab zinc.
Nyob rau hauv nruab nrab ntsev tsuag tshuaj ntsuam tej yam kev mob, lub sij hawm rau zam coated steel coils rau xeb liab yog ntau tshaj 50% ntev tshaj li ntawm cov hlau galvanized nrog tib txheej thickness.
Nyob rau hauv cyclic corrosion test tej yam kev mob, lub sij hawm rau zam steel coils rau xeb liab yog ze li ntawm ob zaug ntev li ntawm GL txheej nrog tib txheej thickness.
2. Kev tiv thaiv corrosion
Qhov tsis zoo corrosion kuj ntawmZAM coated coilsNws zoo dua li cov hlau galvanized.
Nyob rau hauv nruab nrab ntsev tsuag tshuaj ntsuam tej yam kev mob, qhov loj ntawm zinc piv Performance index, qhov ntau dua qhov kev txhim kho nyob rau hauv lub notch corrosion kuj ntawm zam coated steel tshaj galvanized steel.
3. Khob corrosion kuj
Nyob rau hauv nruab nrab ntsev tsuag tshuaj ntsuam tej yam kev mob, lub sij hawm rau zam steel txheej rau xeb liab yog hais txog ob zaug ntev li ntawm cov hlau galvanized.
