Khoom Description
Roofing Sheet yog ib daim ntawv dawb carbon steel coated nyob rau hauv ib tug txheej txheem galvanizing uas siv ib tug barrier ntawm zinc rau insulate nws los ntawm lub ntsiab. Feem ntau ntawm corrugated vov tsev thiab siding khoom pom niaj hnub no thiab ntau xyoo dhau los yog ua los ntawm galvanized tiav. Nws yog feem ntau siv rau kev lag luam, kev ua liaj ua teb, thiab kev lag luam, txawm li cas los xij, tam sim no nws tseem raug lees paub tias yog ib qho zoo heev ntawm cov tsev vov tsev.
Galvanized hlau vov tsev ntawv zoo dua piv nrog ib txwm Ib daim ntawv hlau ib txwm yuav xeb yuav luag tam sim ntawd, tab sis galvanizing yuav tiv thaiv cov hlau. Qhov no galvanized, eltro-coated, kub dipped txheej txheem ua ib tug silvery saib los yog spangled tiav. Raws li tus qauv, ntau yam ntawm peb cov khoom siv hlau, hlau vov tsev, hlau decking, corrugated hlau panels thiab accessories yog ua nyob rau hauv galvanized steel.
Galvanized hlau ru tsev muaj ntau siv nyob rau hauv kev lag luam, domestic, industrial thiab ua liaj ua teb vaj tse, thiab yuav siv tau raws li ib tug - daim tawv vov tsev los yog corrugated sab cladding.
|
Lub npe |
Galvanized vov tsev ntawv |
|
Txuj |
ASTM A653, JIS G3302, GB / T3830-2006 |
|
Qib |
SGCC, DX51D, A653, SGCH, Q235B |
|
Thickness |
0.105mm-0.3 hli |
|
Dav |
1000mm / 900mm, 900mm / 800mm, 762 750 730mm / 665mm |
|
Ntev |
1800mm / 2000mm / 2400mm / 2438mm / 2440mm / 3000mm / 3660mm lossis customized |
|
Zinc txheej |
20-275G/M2 |
|
Ntim |
Txheem seaworthy export pob |
|
Kev xa khoom |
Hauv 10-30 hnub tom qab kos npe rau daim ntawv cog lus |
|
Nqe |
FOB & CFR & CIF nqi |
|
Cov nqe lus them nqi |
T / T lossis L / C |
|
Kev siv |
Kev tsim kho, kev tsim tsheb, nkoj, ntim khoom thiab khoom siv hluav taws xob hauv tsev, Lwm yam kev lag luam siv |
Hlau Khoom Dx51d, Dx52D, Dx53D Zinc Coated Corrugated Galvanized ru tsev Sheet
GI Roofing Steel Sheet feem ntau lojraws li nram no:
1) 762mm txog 665mm (tom qab corrugated) thiab 9 nthwv dej
2) 914mm txog 750mm (tom qab corrugated) thiab 11 nthwv dej
3) 1000mm mus rau 890 los yog 900mm (tom qab corrugated) thiab 12 los yog 14 tsis
Permissable Loads:
Tso cai downward (tsim) loads hauv kN / m2
|
Daim ntawv Thickness |
Qhov hnyav kg / m2 |
Qhov xwm txheej |
Ntev mm |
|||||||||
|
1200 |
1400 |
1600 |
1800 |
2000 |
2200 |
2400 |
2600 |
2800 |
3000 |
|||
|
0.50 hli |
4.78 |
ib leeg |
3.49 |
2.52 |
1.91 |
1.37 |
0.99 |
- |
- |
- |
- |
- |
|
ob npaug |
2.58 |
2 |
1.6 |
1.3 |
1.09 |
0.92 |
0.79 |
- |
- |
- |
||
|
ntau |
3.15 |
2.45 |
1.96 |
1.6 |
1.34 |
1.13 |
0.86 |
- |
- |
- |
||
|
0.70mm ib |
6.22 |
ib leeg |
5.77 |
4.17 |
2.74 |
1.9 |
1.37 |
1.02 |
0.78 |
- |
- |
- |
|
ob npaug |
4.12 |
3.18 |
2.53 |
2.06 |
1.72 |
1.45 |
1.2 |
0.94 |
0.75 |
- |
||
|
ntau |
5.04 |
3.9 |
3.11 |
2.54 |
2.11 |
1.57 |
1.2 |
0.94 |
0.75 |
- |
||
Tso cai cua uplifts (tsis zoo) loads hauv kN / m2
|
Daim ntawv Thickness |
Qhov hnyav kg / m2 |
Qhov xwm txheej |
Ntev mm |
|||||||||
|
1200 |
1400 |
1600 |
1800 |
2000 |
2200 |
2400 |
2600 |
2800 |
3000 |
|||
|
0.50 hli |
4.78 |
ib leeg |
3.62 |
2.62 |
1.98 |
1.52 |
1.1 |
0.82 |
- |
- |
- |
- |
|
ob npaug |
2.52 |
1.95 |
1.56 |
1.27 |
1.06 |
0.89 |
0.77 |
- |
- |
- |
||
|
ntau |
3.09 |
2.39 |
1.91 |
1.56 |
1.3 |
1.1 |
0.94 |
0.82 |
- |
- |
||
|
0.70mm ib |
6.22 |
ib leeg |
5.58 |
4.03 |
3.05 |
2.14 |
1.54 |
1.15 |
0.88 |
- |
- |
- |
|
ob npaug |
4.2 |
3.24 |
2.59 |
2.11 |
1.76 |
1.48 |
1.27 |
1.1 |
0.96 |
0.8 |
||
|
ntau |
5.13 |
3.98 |
3.18 |
2.6 |
2.16 |
1.83 |
1.57 |
1.25 |
0.99 |
0.8 |
||
Galvanized Steel Roofing Panels Kev ua tau zoo thiab kev siv tseem ceeb:
Cov zinc siv lead ua nyob rau saum npoo ntawm cov hlau galvanized tshwm nyob rau hauv cov nplais -zoo li los yog hniav-zoo li qauv. Cov txheej txheej muaj zog galvanized muaj zoo heev corrosion kuj, zoo weldability thiab weldability.
Cold forming zog. Kev siv cov ntawv galvanized steel tuaj yeem muab faib ua kev siv dav dav, siv vov tsev, corrugated vaj huam sib luag vaj huam sib luag siv, kev siv kos duab sib sib zog nqus, thiab lwm yam.
Cov txiaj ntsig ntawm Galvanized Corrugated Sheet Hlau:
Galvanized Corrugated Sheeting yog ib txwm siv profile uas feem ntau siv hauv vov tsev lossis sab cladding tej yaam num. Qhov profile no yog lub teeb yuag thiab yooj yim rau nruab yam tsis tas siv cov cuab yeej nyuaj, txhais tau tias koj cov txheej txheem installation yuav nrawm thiab yooj yim. Cov nplooj ntawv tuaj yeem raug txiav raws li koj qhov kev xav tau tshwj xeeb.
Txhua daim ntawv Galvanized Roof Sheet raug kuaj ntawm nws tus kheej kom ntseeg tau tias nws ua raws li CE EN 14782 cov cai tam sim no.
Kev tswj kom zoo:
Ntim thiab shipping zaub:
Peb cov neeg koom tes:
GNEE Company Profile:
Nrog rau cov kev pabcuam zoo thiab kev tshaj lij, GNEE cov khoom tsis yog tsuas yog muag zoo hauv kev lag luam hauv tsev, tab sis kuj tseem xa tawm mus rau South Asia, Middle East, Africa, Central thiab South America, Europe, Australia thiab lwm lub tebchaws thiab cheeb tsam.
Nrog lub hom phiaj ntawm "tsim kom muaj nuj nqis rau tib neeg thiab cov neeg siv khoom", lub tuam txhab tau cog lus los tsim kom muaj kev txawj ntse, tus kheej thiab qhib kev lag luam. Nrog rau lub zeem muag tshiab, peb yuav ua raws li kev lag luam lub tswv yim ntawm "cov txiaj ntsig me me tab sis kev hloov pauv sai" thiab "kev ncaj ncees yeej lub ntiaj teb", ua tus neeg siv khoom- lub hauv paus, thiab ua siab dawb pab rau lub zej zog. Peb sov siab txais tos cov neeg siv khoom los sib tham txog kev lag luam thiab muab kev taw qhia.
FAQ:
Q: Koj puas yog cov chaw tsim khoom lossis cov lag luam ntawm cov khoom siv galvanized corrugated?
A: Peb yog cov chaw tsim khoom.
Q: Koj ua li cas kom zoo?
A: Peb muaj ib pab neeg soj ntsuam zoo. Peb kuj lees txais qhov thib peb-kev tshuaj ntsuam xyuas, SGS, BV, CICC, ITS, CTl.
Q: Koj puas tuaj yeem muab cov qauv?
A: Yog lawm, peb tuaj yeem muab cov qauv dawb.
Q: Lub voj voog ntau lawm thiab lub sijhawm khoom xa tuaj:
A: Tom qab peb tau txais koj qhov tso nyiaj, ntau lawm yuav kav 20 mus rau 40 hnub.
Cim npe nrov: galvanized corrugated vov tsev ntawv, Tuam Tshoj galvanized corrugated vov tsev ntawv manufacturers, lwm tus neeg, Hoobkas
