GNEE txias-dov dov cov ntawv hauv tsev yog cov khoom tseem ceeb ntawm GNEE txias-dov cov kab ntau lawm. Cov khoom zoo tau mus txog qib siab ntawm kev lag luam hauv tsev. Ntawm lawv, cov khoom siv hauv tsev nyias nyias (tsawg dua lossis sib npaug ntawm 0.4mm) tau dhau los ua cov khoom lag luam tseem ceeb hauv khw. Cov qib tseem ceeb yog DC01-DC06, spcc, thiab lwm yam. Peb lub koom haum koom tes suav nrog cov pab pawg neeg paub zoo xws li Anshan Hlau thiab Hlau, Baosteel, thiab Hegang. Peb cov khoom tau tsim kev sib raug zoo nrog kev sib raug zoo nrog cov tuam txhab lag luam hauv tsev xws li Gree, Midea, Haier, TCL, thiab BOE.
Kev taw qhia txog qib thiab kev siv cov hlau rau kev kos duab series
| Khoom qeb | Standard thiab qib | Sib npaug txawv teb chaws tus qauv | Kev piav qhia | |||
| Baosteel cov qauv kev lag luam | Txheem naj npawb | Txheem naj npawb | Qib | |||
| Kev siv dav dav | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 | SPCC DC01 BLC | EN10327 JISG3141 | SPCC DC01 JSC 270C | Hlau rau kev shaping thiab ua cov tub yees thiab lwm yam khoom siv hauv tsev plhaub, roj nruas, steel rooj tog | |
| Siv rau kev kos duab | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 | SPCD DC03 TSI | EN10327 JISG3141 | SPCD DC03 JSC270D UAS | Hlau rau kev kos duab thiab shaping ntawm cov khoom siv hauv tsev | |
| Siv rau kev kos duab sib sib zog nqus | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 | SPCE DC04 TSI | EN10327 JISG3141 | SPCE DC04 JSC270E | Hlau rau sib sib zog nqus kos duab thiab shaping txheej txheem | |
| Siv rau kev kos duab sib sib zog nqus tshwj xeeb | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 | SPCF (SPCEN) DC05 BUFD | EN10327 JISG3141 | SPCF DC05 JSC270F | Hlau rau tshwj xeeb sib sib zog nqus kos duab thiab shaping txheej txheem | |
| Kev kos duab sib sib zog nqus | Q/BQB402-2009 Q/BQB403-2009 Q/BQB408-2009 | SPCG DC06 BSUFD UAS | EN10327 JISG3141 | SPCG DC06 JSC260G 1 | Hlau rau tshwj xeeb sib sib zog nqus kos duab thiab shaping txheej txheem | |
| Siv rau tshwj xeeb kos duab tob | Q/BQB403-2009 | dc07 ua | EN10327 JISG3141 | dc07 ua | Hlau nrog tshwj xeeb zoo sib sib zog nqus nqus khoom | |
| Siv rau lub vaj huam sib luag ntawm cov khoom siv hauv tsev | BZJ471-2009 | BLC-JD1 | Rau spraying ( ci hardening ) | Outer phaj ntawm lub tshuab ntxhua khaub ncaws | ||
| BLC-JD2 | Sab nrauv ntawm lub freezer | |||||
| BLC-JD3 | Lub tub yees sab vaj huam sib luag thiab lub tub yees me me rau kev txau | |||||
| BLD-JD1 | Rau kev siv tectorial (aging reslstance) | Lub tub yees tectorial vaj huam sib luag rau kev sib sib zog nqus kos duab | ||||
| BLD-JD 2 | Lub tub yees tectorial vaj huam sib luag rau kev kos duab | |||||
| BLD-JD 3 | Lub tub yees tectorial vaj huam sib luag rau kev siv dav dav | |||||
Mechanical zog ntawm steel drawing series
| Qib | MPa Yield zog | MPa Tensile zog (tsis tsawg dua) | Elongation% A80mm (tsis tsawg dua) | r90 | n90 | |||||
| mm Nominal thickness | Tsis tsawg dua | |||||||||
| <0.30 | 0.30 ~<0.50 | 0.50 ~ <0.70 | 0.70 ~ <1.0 | 1.0~<1.6 | Ntau dua lossis sib npaug rau 1.6 | |||||
| dc01 ua | 140 ~ 280 | 270 | 24 | 26 | 28 | 30 | 32 | 34 | - | - |
| dc03 ua | 140 ~ 240 | 270 | - | 30 | 32 | 34 | 35 | 36 | 1.3 | - |
| dc04 ua | 130 ~ 210 | 270 | - | 34 | 36 | 38 | 39 | 40 | 1.6 | 0.18 |
| dc05 ua | 120 ~ 180 | 270 | - | 35 | 38 | 40 | 40 | 41 | 1.9 | 0.2 |
| dc06 ua | 110 ~ 170 | 260 | - | 37 | 39 | 41 | 42 | 43 | 2.1 | 0.22 |
| dc07 ua | 100 ~ 150 | 250 | - | 40 | 42 | 44 | 2.5 | 0.23 | ||
| Qib | MPa Yield zog | MPa Tensile zog (tsis tsawg dua) | Elongation % (L0=50mm, b=25mm) (tsis tsawg dua) | rm (tsis tsawg dua) |
|||||||
| mm Nominal thickness | mm Nominal thickness | ||||||||||
| <0.25 | 0.25 ~<0.30 | 0.30 ~ <0.40 | 0.40 ~ <0.60 | 0.60~<1.0 | 1.0~<1.6 | Ntau dua lossis sib npaug rau 1.6 | 0.5~<1.0 | 1.0~<1.6 | |||
| SPCC | - | 270 | 25 | 28 | 31 | 34 | 36 | 37 | 38 | - | - |
| SPCD | 240 | 270 | 27 | 30 | 33 | 36 | 38 | 39 | 40 | - | - |
| SPCE | 220 | 270 | 29 | 32 | 35 | 38 | 40 | 41 | 42 | - | - |
| SPCF (SPCEN) | 210 | 270 | - | - | 37 | 40 | 42 | 43 | 44 | - | - |
| SPCG | 190 | 270 | - | - | - | 42 | 44 | 45 | 46 | 1.4 | 1.3 |
| Qib | MPa Yield zog | MPa Tensile zog (tsis tsawg dua) | Elongation %(L0=50mm,b=25mm) (Tsis pub tsawg dua) | r90 | n90 | |||
| mm Nominal thickness | Tsis tsawg dua | |||||||
| <0.60 | 0.60 ~<1.0 | 1.0 ~<1.6 | Ntau dua lossis sib npaug rau 1.6 | |||||
| BLC | 140 ~ 270 | 270 | 36 | 38 | 40 | 42 | - | - |
| BLD | 120 ~ 240 | 270 | 38 | 40 | 42 | 44 | 1.5 | 0.18 |
| BUSD | 120 ~ 210 | 260 | 40 | 42 | 44 | 46 | 1.7 | 0.2 |
| BUFD | 120 ~ 190 | 250 | 42 | 44 | 46 | 48 | 2 | 0.21 |
| BSUFD | 110 ~ 180 | 250 | 44 | 46 | 48 | 50 | 2.2 | 0.22 |
Muaj ntau yam steel rau kos series
| Yam khoom | mm Nominal loj | |
| Thickness | 0.25-3.5 | |
| Dav | 800-1830 | |
| Ntev | Hlau phaj | 1000-6000 |
| Hlau strip | Coil hauv txoj kab uas hla 508, 610 | |
Kev taw qhia txog qib thiab kev siv cov hlau rau lub plhaub roj teeb
| Qib | Siv |
| BDCK | Roj teeb plhaub |
Mechanical zog ntawm steel rau roj teeb plhaub
| Qib | Tensile zog Tsis tsawg tshaj MPa |
A50 mm Elongation Tsis tsawg dua% |
Hardness HRB |
| BDCK | 275 | 34 | 40~56 |
| a. Cov qauv yog P14 qauv hauv GB / T228 | |||
Muaj ntau yam steel rau roj teeb plhaub
| mm Nominal thickness |
mm Thickness kam rau ua |
mm Nominal dav |
mm Dav kam rau ua |
mm Sab hauv diameter ntawm steel sawb |
Muaj cov qauv saum npoo |
| 0.25-0.30 | -0.007~+0.003 | Nrog txiav ntug: 800-1005 | Nrog txiav ntug: 0-+3 | 508 | Smooth nto (B) |
| 0.25-0.50 | ±0.01 | Tsis muaj kev txiav ntug: 800 ~ 1020 | Tsis txiav ntug:0~+5 | Plua plav nto (D) |
Kev taw qhia txog qib thiab kev siv cov khoom txias-dov hlau rau enamel
| Qib | Siv |
| dc03 ua | Cold-rolled steel phaj rau ncaj enamel |
| DC04ED (BTC4D) | |
| dc06 ua | Txias-rolled steel phaj rau ob zaug enamel |
| dc01 ua | Enamel txias dov steel phaj rau kev sib sib zog nqus nqus |
| dc04 ua | |
| dc06 ua | |
| BTC 1 |
Mechanical zog ntawm txias-dov hlau rau enamel
| ReL los yog Rp0.2MPa | RmMPa | A80% | r90 | |
| dc03 ua | Tsawg dua lossis sib npaug li 240 | 270-350 | Ntau dua lossis sib npaug li 34 | |
| dc04 ua | Tsawg dua lossis sib npaug li 210 | 270-350 | Ntau dua lossis sib npaug li 38 | |
| dc06 ua | Tsawg dua los yog sib npaug li 190 | 270-350 | Ntau dua lossis sib npaug li 38 | Ntau dua lossis sib npaug rau 1.6 |
| dc01 ua | Tsawg dua lossis sib npaug li 270 | 270-390 | 30 | |
| dc04 ua | Tsawg dua los yog sib npaug li 220 | 270-350 | 36 | |
| dc06 ua | Tsawg dua los yog sib npaug li 190 | 270-350 | 38 | Ntau dua lossis sib npaug rau 1.6 |
| BTC 1 | Tsawg dua los yog sib npaug li 190 | 270-320 | Ntau dua lossis sib npaug li 39 |
Muaj ntau yam ntawm txias-kuav los tiag steel rau enamel
| lwm | mm npe | |
| Thickness | 0.3-3.0 | |
| Dav | 720-1650 | |
| Ntev | Hlau phaj | 1000-6000 |
| Hlau strip | Coil hauv txoj kab uas hla 508,610 | |
Taw qhia txog cov khoom siv kho mob saum npoo
| Kub-dip galvanized steel ntawv | Electro-galvanized steel ntawv |
| 55% Al-Zn alloy galvanized steel ntawv | PPGI / PPGL |
Painting technology ntawm steel rau cov khoom siv
Taw qhia txog qhov feature
1. Txhim kho lub neej kev pab cuam ntawm steel qhov chaw hauv cov khoom siv hauv tsev
Txhua qhov hlau yuav xeb thiab rot hauv huab cua los ntawm kev sib cuag thiab nkag nrog cov xov xwm corrosive (O2, H2O, CI, thiab lwm yam nyob rau hauv cov huab cua) kom txog thaum lawv poob lawv cov qub mechanical zog. Txhawm rau ncua qhov tshwm sim ntawm xeb, feem ntau siv txhais tau tias Nws yog siv cov organic txheej rau ntawm qhov chaw ntawm cov hlau kom cais cov hlau los ntawm cov xov xwm corrosive thiab ua lub luag haujlwm tiv thaiv lub cev.
2. Kho kom zoo nkauj
Los ntawm daim ntawv thov ntawm cov organic coatings, qhov txias thiab monotonous tsos ntawm steel daim hlau tuaj yeem hloov pauv tag nrho. Organic coatings tuaj yeem muab cov hlau phaj ntau xim thiab textures kom tau raws li qhov xav tau ntawm kev zoo nkauj.
Vim li cas thiaj xaiv GNEE cov khoom siv hauv tsev txias?
GNEE STEEL tuaj yeem ua tau raws li cov kev xav tau ntawm cov khoom siv hauv tsev loj xws li cua txias, tshuab ntxhua khaub ncaws, tub yees, thiab khoos phis tawj. Kev muab khoom txhua xyoo ntawm GNEE cov khoom siv hauv tsev tam sim no nce mus txog kwv yees li 300, 000 tons, suav nrog cov khoom siv txias dov, kub-dip galvanized (aluminium) zinc cov khoom, thiab cov khoom siv hluav taws xob-galvanized.
GNEE siv cov thev naus laus zis hauv chav kawm thawj zaug, cov khoom siv thiab cov kev pabcuam kev lag luam los ua kom cov khoom siv hauv tsev ua kom tau raws li cov kev xav tau ntawm cov neeg siv. Los ntawm kev txiav txim siab qib siab thiab kev tswj xyuas kev ua haujlwm thiab kev xa khoom, GNEE ua kom cov khoom xa tuaj rau lawv qhov chaw raws sijhawm.
GNEE them nyiaj rau kev tiv thaiv ib puag ncig. Thaum tswj xyuas kev tsim khoom huv si thiab tsim kom muaj GNEE ntsuab, nws tau cog lus rau kev tshawb fawb thiab kev tsim cov khoom zoo ib puag ncig kom ua tau raws li cov kev cai ntawm kev lag luam hauv tsev rau cov neeg muag khoom. Cov ntaub ntawv muab tsis muaj cov khoom tsis zoo hauv RoHS cov lus qhia thiab tsis txhob siv cov khoom siv dag zog hauv cov txheej txheem tsim khoom. Kev yuav tsum tau ntxiv cov khoom tsim kev puas tsuaj.
GNEE yog tag nrho ntawm qhov tseem ceeb thiab txoj hauv kev loj hlob, thiab tos ntsoov yuav tsim lub neej niaj hnub nrog koj.
